Spectrophotometer Colorimeter series ARW 3-60 / ARW 3-20 / ARW 3-10

Portable Spectrophotometer Series ARW 3-60 / ARW 3-20 / ARW 3-10

The ARW 3-60 / 3-20 / 3-10 series of portable spectrophotometers are instruments with high precision and are designed for color matching, color analysis and measurement protocols and for the formulation of matrices to define the color.

They have a modern design but at the same time have advanced features that make them extremely simple to use.

The models in the series are:

• ARW 3-60 Spectrophotometer equipped with special UV illumination to measure samples and complete illuminants, 8mm and 4mm apertures, SCI & SCE, Bluetooth communication and is equipped with very high precision and extended functions with management software via PC. It represents a fundamental tool for responding to the most advanced needs in industrial color measurement management.
• ARW 3-20 Spectrophotometer with multi-illuminants, aperture on demand, equipped with SCI & SCE, Bluetooth connection and very high accuracy (PC software included).
• ARW 3-10 Spectrophotometer equipped with 4 illuminants, 8 mm aperture, SCI & SCE and excellent precision (PC software included).

​The instruments comply with CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724/1,ASTM E1164,DIN5033 Teil7 regulations.

Main features Spectrophotometers ARW 3-60 / ARW 3-20 / ARW 3-10

• The perfect combination of beautiful appearance and the human body mechanics structural design.
• D/8 geometrical optics, conforms with CIE No.15,GB/T 3978,GB2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil.
• Large capacity storage space, over 20,000 measurement data.
• High electronic hardware configuration: 3.5-inch TFT color LCD, Capacitive Touch Screen, concave grating, 256 Iimage Element Double Arrays CMOS Image Sensor.
• Standard white calibration plate, highly stain-resistant, supplied.
• Use long life and low power consumption combined LED light source.
• Measure sample spectra, accurate Lab data , can be used in color matching and accurate color transmission.
• Equipped with a camera that allows you to precisely view and center the exact point of the measurement.
• Supplied with USB output and data management and processing software.
• Single 8mm aperture that supports both SCI and SCE modes simultaneously.
• Numerous functions available such as two standard viewing angles, a variety of illuminants and color indices, it complies with numerous standard colorimetric data and is the ideal tool to meet color measurement requirements.

Applications of the ARW 3-60 / 3-20 / 3-10 Spectrophotometers

The Spectrophotometer series is ideal for numerous industrial activities.

It is widely used in the plastic manufacturing industry, electronics, painting, ink, textile and clothing, printing and dyeing, printing paper, automotive industry, medical industry, cosmetics, food industry, scientific research institutes, schools and laboratories.
