Coating thickness gauge ARW-826

The ARW-826 thickness gauge is designed for measuring the thickness of the coating layer such as paint, enamel, zinc, chrome, etc. It is equipped with an external probe for measures on ferrous and non-ferrous "FN" substrates.

‹ ›

Product Code: 220121334
Availability: In Stock

Coating thickness gauge with integrated probe

"FN" dual technology measurement system for magnetic and non-magnetic metal substrates.
Equipped with zeroing bases and sample thicknesses for verification and calibration.
Supplied in a sturdy ABS case.
Large 4-digit LCD display and low battery warning.

490.00€

Ex Tax: 490.00€

Further information

Coating thickness gauge ARW 826 FN

The ARW 826 coating thickness gauge is a simple and precise instrument suitable for measuring coating thicknesses on metal surfaces.
ARW-826 FN model for the measurement of the thickness of any type of coating (paint, plastic, zinc, chrome, aluminium, stainless steel, copper, rubber, ceramic, etc.) on non-ferrous, non-magnetic (NFE) metal bases.

Main features Coating Thickness gauge ARW-826FN

High value for money
Complete with separate probe with extensible cable suitable for any type of flat or round surface.
Simple and fast calibration with the supply of 4 reference thicknesses (50 - 100 - 200 -500 μm).
Large 4-digit LCD display
Low battery warning
Supplied complete with ABS case, 2 measuring probe, 2 zeroing base, 4 calibration foils and user manual.

Technical specifications thickness gauge ARW-826
Measuring range	0-1250 µm FE/NFE
Risolution	0,1µm up to 100 µm- 1 µm up to 1250 µm
Accuracy	±3% of reading or ±2 µm
Operating temperature	0 +50°C
Operating humidity	<80%
Power supply	4 batteries 1,5V (AA-UM3)
Instrument size	161x69x32mm
Probe size	ø15mm-H 55mm
